App-48
IM 04L31A01-17E
*9 Registers D7801–D7803 (status of control module DI), 37004 (status of expansion module DI), D7811–
D7813 (status of control module DO), D7814 (status of expansion module DIO), and D7821–D7823
(status of internal switches) show the status of each bit in the register (16-bit). The status of the DIO and
internal switches are shown in order from the last bit in the register.
0
1
2
3
4
5
6-15
DI001(0: OFF, 1: ON)
DI002(0: OFF, 1: ON)
DI003(0: OFF, 1: ON)
DI004(0: OFF, 1: ON)
DI005(0: OFF, 1: ON)
DI006(0: OFF, 1: ON)
Unused
Bit
Bit and DI status
Bit Configuration of Register D7801
0
1
2
3
4
5
6
7
8
9
10
11
12-15
RO001(0: OFF, 1: ON)
RO002(0: OFF, 1: ON)
RO003(0: OFF, 1: ON)
RO004(0: OFF, 1: ON)
RO005(0: OFF, 1: ON)
RO006(0: OFF, 1: ON)
RO007(0: OFF, 1: ON)
RO008(0: OFF, 1: ON)
RO009(0: OFF, 1: ON)
RO010(0: OFF, 1: ON)
RO011(0: OFF, 1: ON)
RO012(0: OFF, 1: ON)
Unused
Bit
Bit and DO of expanded DIO module status
Bit Configuration of Register D7814
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
SW001(0: OFF, 1: ON)
SW002(0: OFF, 1: ON)
SW003(0: OFF, 1: ON)
SW004(0: OFF, 1: ON)
SW005(0: OFF, 1: ON)
SW006(0: OFF, 1: ON)
SW007(0: OFF, 1: ON)
SW008(0: OFF, 1: ON)
SW009(0: OFF, 1: ON)
SW010(0: OFF, 1: ON)
SW011(0: OFF, 1: ON)
SW012(0: OFF, 1: ON)
SW013(0: OFF, 1: ON)
SW014(0: OFF, 1: ON)
SW015(0: OFF, 1: ON)
SW016(0: OFF, 1: ON)
Bit
Bit and internal switch status
Bit Configuration of Register D7821
0
1
2
3
4-15
SW033(0: OFF, 1: ON)
SW034(0: OFF, 1: ON)
SW035(0: OFF, 1: ON)
SW036(0: OFF, 1: ON)
Unused
Bit
Bit and internal switch status
Bit Configuration of Register D7823
Appendix 6 Register Assignments
