Command
RL: Select remote/local
0: Local operation
1: Remote operation (cannot be
selected in the following cases.
UT420/UT450/UT520/UT550:
control mode is single loop and no
control hold function
UT750: control mode is cascade
secondary
Not available with UT320/UT321/
UT350/UT351
SR: Operation start/stop
0: Operation start
1: Operation start
Not available depending on the UT
operation mode
MOUT: Changing the control output value
(available during manual operation)
During On/off control: 0.0%,
100.0%
When other than onoff control:
-5.0% to 105.0%
SPN: Switching the target setpoint
number
1: Select target setpoint number 1
:
8: Select target setpoint number 8
For UT320/UT321/UT350/UT351,
can select 1–4
Example Run external loop 2 automatically.
DV2,MODE,0
6.5 Setting Commands (Measurement)
6.5 Setting Commands
(Measurement)
SR Sets the input range
When setting channels to skip
Syntax SR p1,p2
p1: Channel number (01 to 20) (01 to 06 on the
CX1000)
p2: Range mode (SKIP)
Query SR[ p1]?
Example Set channel 01 to skip.
SR01,SKIP
Description • This command cannot be specified while
measurement/computation is in progress or
while a report is being created.
• Measurements are not made on channels that
are set to SKIP.
When setting the channels to voltage, TC, RTD, or
ON/OFF input
Syntax SR p1,p2,p3,p4,p5
p1: Channel number (01 to 20) (01 to 06 on the
CX1000)
p2: Input type
VOLT DC voltage
TC TC
RTD RTD
DI ON/OFF input
p3: Measurement range
p4: Span lower limit
p5: Span upper limit
Query SR[ p1]?
Example Set the input type for channel 01 to TC type R,
span lower limit to 0°C, and span upper limit to
1760.0°C.
SR01,TC,R,0,17600
Description • This command cannot be specified while
measurement/computation is in progress or
while a report is being created.
• Set parameters p3, p4, and p5 according to
the table in section 6.3.
• For parameters p4 and p5, enter a value using
5 digits or less excluding the decimal point.
The decimal position is fixed to the position
indicated in the table in section 6.3.
When computing the difference between channels
Syntax SR p1,p2,p3,p4,p5,p6,p7
p1: Channel number (01 to 20) (01 to 06 on the
CX1000)
p2: Range mode (DELTA)
p3: Input type
VOLT DC voltage
TC TC
RTD RTD
DI ON/OFF input
