6-63
IM 04L31A01-17E
6
Command
6.15 Instrument Information Output Commands
6.15 Instrument Information
Output Commands
(Available when using the
instrument information
server function via
Ethernet communications)
The instrument information server function interprets one
UDP packet to be one command and returns a single packet
(containing the CX information) in response to the command.
Port number 34264/udp
(see section 2.1)
Transfer data ASCII
Received buffer length 128
Transmit buffer length 512
Maximum number of parameters 32
In the command packet, parameters corresponding to the
desired information are placed one after another.
Parameter Description
all Outputs all information that is output using the
parameters below (serial, model, host, ip).
serial Outputs the serial number.
model Outputs the manufacturer, model, and
firmware version.
host Outputs the host name (the host name
specified in section 2.3).
ip Outputs the IP address (the host name
specified in section 2.3).
Example Query the IP address and host name. (Of the
two frames below, the top frame represents the
command packet, the bottom frame represents e
response packet.)
ip host
EA
ip = 192.168.111.24
host = CX2000
EN
Description • Separate each parameter with one or more
blanks (space, tab, carriage return, line feed).
• Parameters are not case sensitive.
• Undefined parameters will be ignored.
• Parameters beyond the 32nd parameter are
ignored.
