2-26
IM 04L31A01-17E
2.9 Setting the Web Server Function
Explanation
To use the Web server function, set the following parameters in addition to those
described in section 2.3.
Enabling/Disabling the Web Server Function
Select [Use] or [Not] (don’t use).
Page Type (Type of Screen to Be Displayed)
• Monitor
• The screen displayed on the CX is displayed.
• The following information can be displayed.
• Alarm summary
• Measurement/computation channel values
• Control channel values
• Log (error message log, login/logout log, FTP file transfer log, e-mail
transmission log, and Web browser operation log)
• For screen examples, see section 2.10.
• Operator
The following operations can be carried out in addition to the functions available on
the monitor page.
• Switch the screen on the CX using the display selection menus.
• Operate the DISP/ENTER key and arrow keys on the CX.
• Set messages on the CX and write them.
• For screen examples, see section 2.10.
Monitor Page
• Selecting whether to use the monitor page
• On
The monitor page can be displayed on a Web browser.
• Off
Disables the use of the monitor page.
• Selecting whether use the access control
• On
Enables the use of access control. You must enter the user name and
password to display the monitor page.
• Off
Disables the use of access control.
• Setting the user name
Set the user name using up to 16 alphanumeric characters.
• Setting the password
Set the password using up to six alphanumeric characters.
Operator Page
• Selecting whether to use the operator page
• On
The operator page can be displayed on a Web browser.
• Off
Disables the use of the operator page.
