Yokogawa Data Acquisition with PID Control CX2000 User Manual
Page 225

7-33
IM 04L31A01-17E
7
Response
CX1000
DIO1-6
DIO1
DIO7
DIO1-6
DIO1-6
DIO1-6
DIO7-12
DIO2
DIO8
DIO7-12
DIO7-12
DIO7-12
DIO3
DIO9
DIO4
DIO10
DIO5
DIO11
DIO6
DIO12
1 byte
1 byte
1 byte
1 byte
1 byte
1 byte
Status (Active/Inactive) of DIO operation
monitoring function
DIO type
DIO type
Operation setting of DIO operation monitoring function
Status of DIO operation monitoring function input
Status of DIO operation monitoring functionoutput
Data details
DIO operation monitoring function setting status
DIO-1-6 (1 byte)
bit0:
DIO operation monitoring function status setting of DIO operation
monitoring 1 (1: active, 0: inactive)
bit1:
DIO operation monitoring function status setting of DIO operation
monitoring 2 (1: active, 0: inactive)
:
bit5:
DIO operation monitoring function status setting of DIO operation
monitoring 6 (1: active, 0: inactive)
bit6–bit7: 0
Shows whether the DIO operation monitoring setting for each DIO operation
monitoring number is active. Assigns the active/inactive DIO operation monitoring
setting to bits 0 through 5 from the smallest DIO monitoring number to the largest for
other bytes as well.
DIO type setting
DI01 (1 byte), the DIO type for DI01
0: DI-1 (default setting), 1:DO-1,2: DO-2,3: DIO-12,4: DIO12,5: DO-2P,6: DIO-12P
Outputs the DIO type for DI01–DIO36 (or DIO12 for the CX1000)
Operation Setting for DIO Operation Monitoring
DI01–6 (1 byte)
bit0:
Auto/manual status of DIO operation monitoring 1 (0: manual, 1:
automatic).
bit1:
Auto/manual status of DIO operation monitoring 2 (0: manual, 1:
automatic).
:
bit5:
Auto/manual status of DIO operation monitoring 6 (0: manual, 1:
automatic).
bit6–bit7: 0
Shows the auto/manual status of DIO operation monitoring for each DIO operation
monitoring number. Assigns the auto/manual DIO operation monitoring status to bits
0 through 5 from the smallest DIO monitoring number to the largest for other bytes as
well. Sets auto/manual status of inactive DIO operation monitoring items to 0.
7.3 Output Format of BINARY Data
