6-32
IM 04L31A01-17E
6.5 Setting Commands (Measurement)
Example Set the display direction of the trend waveform to
horizontal, the direction of the bar graph to
vertical, the measurement background color to
white, the control background color to white, the
line width of the trend to 1 dot, the width of the
trip line to 2 dots, the number of grids to 10, the
time interval for switching displayed group to
20s, and the scale display digits to normal.
SEHORIZONTAL,VERTICAL,WHITE,WHITE,
1,2,10,20s,NORMAL
SB Sets the number of scale
divisions, base position of the
bar graph, and the display
position of the trend scale
Syntax SB p1,p2,p3,p4
p1: Channel number (01 to 20, 31 to 60, 101 to
118, 201 to 248) (01 to 06, 31 to 42, 101 to
106, 201 to 212 on the CX1000)
p2: Number of scale divisions (4 to 12, C10)
p3: Base position of the bar graph display
(NORMAL, CENTER)
p4: Position of the scale for the trend display
(OFF, 1 to 10 (1 to 6 on the CX1000))
Query SB[ p1]?
Example Set the number of scale divisions of the bar
graph of channel 02 to 5, and display the bar
graph from the span lower limit (scale lower limit
if scale is enabled). Display the scale at the third
position.
SB02,5,NORMAL,3
Description • Computation channels (31 to 60) can only be
specified on models with the computation
function option /M1.
• The base position (p3) is valid when the
display direction of the bar graph is set to
HORIZONTAL. Use the SE command to set
the display direction of the bar graph.
SV Sets the rolling average of the
measured channel
Syntax SV p1,p2
p1: Channel number (01 to 20) (01 to 06 on the
CX1000)
p2: Number of samples for computing the rolling
average (OFF, 2 to 16) [times]
Query SV[ p1]?
Example Set the number of samples for computing the
rolling average of channel 02 to 12.
SV02,12
SC Sets the channel display color
Syntax SC p1,p2
p1: Channel number (01 to 20, 31 to 60, 101 to
118, 201 to 248) (01 to 06, 31 to 42, 101 to
106, 201 to 212 on the CX1000)
p2: Display color (RED, GREEN, BLUE,
B.VIOLET, BROWN, ORANGE, Y.GREEN,
LIGHTBLUE, VIOLET, GRAY, LIME, CYAN,
DARKBLUE, YELLOW, LIGHTGRAY,
PURPLE)
Query SC[ p1]?
Example Set the display color of channel 02 to blue.
SC02,BLUE
Description Computation channels (31 to 60) can only be
specified on models with the computation
function option /M1.
SQ Sets the LCD brightness and the
screen backlight saver
When turning OFF the screen backlight saver
function
Syntax SQ p1,p2
p1: LCD brightness (1 to 4) (1 to 8 on the
CX1000)
p2: Screen backlight saver function ON/OFF
(OFF)
Query SQ?
Example Set the LCD brightness to 2 and the screen
backlight saver function to OFF.
SQ2,OFF
When turning ON the screen backlight saver
function
Syntax SQ p1,p2,p3,p4
p1: LCD brightness (1 to 4) (1 to 8 on the
CX1000)
p2: Screen backlight saver function ON/OFF
(ON)
p3: Time after which to enable the screen saver
function (1MIN, 2MIN, 5MIN, 10MIN, 30MIN,
1H)
p4: Factors that cause the screen to return from
the saver mode (KEY, KEY+ALM)
Query SQ?
Example Set the LCD brightness to 2, the screen backlight
saver function to ON, the time after which to
enable the screen backlight saver function to
1MIN, and the factor that causes the screen to
return from the saver mode to KEY.
SQ2,ON,1MIN,KEY
