App-42
IM 04L31A01-17E
Appendix 6 Register Assignments
• Program Individual Control Parameters
D8101
D8102
D8103
D8104
D8105
D8106
D8107 to D8112
D8113 to D8118
D8119 to D8124
D8125 to D8130
D8131
D8132
D8133
D8134
D8135
D8136
:
D8146
D8147
D8148
D8149 to D8154
Pattern number used as pattern
id1
Pattern number used as pattern
id2
Pattern number used as pattern
id3
Pattern number used as pattern
id4
Pattern number used as pattern
id5
Pattern number used as pattern
id6
Run/stop programs of patterns
id1–6
Run/hold programs of patterns
id1–6
Segment number of executing
pattern id1–6
Number of segments of pattern
id1–6
Remaining segment time (hh) of
pattern id1
Remaining segment time (mm)
of pattern id1
Remaining segment time (ss) of
pattern id1
Remaining segment time (hh) of
pattern id2
Remaining segment time (mm)
of pattern id2
Remaining segment time (ss) of
pattern id2
:
Remaining segment time (hh) of
pattern id6
Remaining segment time (mm)
of pattern id6
Remaining segment time (ss) of
pattern id6
Wait status
1: Pattern number 1
:
30: Pattern number 30
1: Pattern number 1
:
30: Pattern number 30
1: Pattern number 1
:
30: Pattern number 30
1: Pattern number 1
:
30: Pattern number 30
1: Pattern number 1
:
30: Pattern number 30
1: Pattern number 1
:
30: Pattern number 30
0: stop, 1: run
0: none, 1: holding
0–99. However 0 indicates the time until
the program pattern starts running after
the program starts running.
1-99
0-59* 3
0-59* 3
0-59* 3
0-59* 3
0-59* 3
0-59* 3
:
0-59*
3
0-59* 3
0-59* 3
0:None
1: waiting
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
D Register
Number
Description Register Type Value
Read/
Write
