App-32
IM 04L31A01-17E
D1101
D1102
D1103
D1104
D1105
D1106
D1107
D1108
D1109
D1110
D1111
D1112
D1125
D1126
D1127
D1128
D1131-D1142
D1155-D1158
D1161-D1172
PID parameter of
PID number 1 of
loop 1
Control alarm
value of PID
number 1 of loop 1
PID parameter of
PID number 2 of
loop 1
Control alarm
value of PID
number 2 of loop 1
PID parameter of
PID number 3 of
loop 1
Target setpoint (SP)
Proportional band (P)
Integral time (I)
Derivative time (D)
Output low-limit
Output high-limit
Shutdown function enable/disable
Manual reset
Hysteresis value
Hysteresis activation point
Control action direction switching
Preset output
Control alarm value
(Alarm number 1)
Control alarm value
(Alarm number 2)
Control alarm value
(Alarm number 3)
Control alarm value
(Alarm number 4)
Same as the PID parameters of
PID number 1 of loop 1
Same as the control alarm
values of PID number 1 of loop 1
Same as the PID parameters of
PID number 1 of loop 1
Within the measurement span excluding the
decimal point
1 to 9999: 0.1 to 999.9%
0 to 6000
0 to 6000
–50 to 1050: –5.0% to 105.0%
–50 to 1050: –5.0% to 105.0%
0: OFF
1: ON
–50 to 1050: –5.0% to 105.0%
Within the measurement span excluding the
decimal point
0: OFF
1: Upper
2: Lower
0: Reverse
1: Direct
–50 to 1050: –5.0% to 105.0%
Varies depending on the alarm type as
follows:
SP/PV alarm
Within the measurement span excluding
the decimal point
Deviation alarm (high-limit and low-limit)
Within EUS –100.0 to 100.0% of the
measurement span excluding the decimal
point
Deviation alarm (high & low limit and within
high & low limits)
Within EUS 0.0 to –100.0% of the
measurement span excluding the decimal
point
Output alarm
–50 to 1050: –5.0% to 105.0%
(See the AV command)
Same as above
Same as above
Same as above
Same as the range for the PID parameters
of PID number 1 of loop 1
Same as the range for the control alarm
values of PID number 1 of loop 1
Same as the range for the PID parameters
of PID number 1 of loop 1
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
D Register
Number
Description Register Type Value
Read/
Write
Appendix 6 Register Assignments
