• Write Registers for DO/internal switches

44501
44502
44503
44504
44505
44506
44507 to 44512
44513 to 44518
44519 to 44530
44531 to 44600
44601 to 44636

0: OFF, 1: ON
0: OFF, 1: ON
0: OFF, 1: ON
0: OFF, 1: ON
0: OFF, 1: ON
0: OFF, 1: ON
0: OFF, 1: ON
0: OFF, 1: ON
0: OFF, 1: ON

0: OFF, 1: ON

R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W

R/W

Modbus

Register

Number

Description

Register

Type

Value

Read/

Write

DO001
DO002
DO003
DO004
DO005
DO006
DO101 to DO106
DO201 to DO206
RO001 to RO012
Reserved
SW001 to SW036
