p4: Internal switch number (SW001-SW036, or
SW001-SW018 for the CX1000)
p5: ON DO number (DI001-DI006, DI101-
DI106, DI201-DI206, RI001-RI012, or
DI001-DI006 for the CX1000)
p6: OFF DO number (DI001-DI006, DI101-
DI106, DI201-DI206, RI001-RI012, or
DI001-DI006 for the CX1000)
Query
DX p1?
Example
Set DIO operation monitoring number 2 so that
the ON status of internal switch SW003 is output
from DO002, and the OFF status is output from
DO003, and monitored.
DX2,ON,DO-2,SW003,DO002,DO003
When set to DIO-11
Syntax
DX p1,p2,p3,p4,p5,p6
p1: DIO operation monitoring function number
(01–36, 01–12 for the CX1000)
p2: ON(Off/On)
p3: Type (DI-1, DO-1, DO-2, DIO-11, DIO-12,
DO-2P, DIO-12P)
Set to DIO-11 here.
p4: Internal switch number (SW001-SW036, or
SW001-SW018 for the CX1000)
p5: DO number (DI001-DI006, DI101-DI106,
DI201-DI206, RI001-RI012, or DI001-DI006
for the CX1000)
p6: DI number (DI001-DI006, DI101-DI106,
DI201-DI206, RI001-RI012, or DI001-DI006
for the CX1000)
Query
DX p1?
Example
Set DIO operation monitoring number 2 to so
that the status of internal switch SW003 is output
from DO002, and DIO03’s status is monitored.
DX2,ON,DIO-11,SW003,DO002,DI003
When set to DIO-12 or DIO-12P
Syntax
DX p1,p2,p3,p4,p5,p6,p7
p1: DIO operation monitoring function number
(01–36, 01–12 for the CX1000)
p2: ON(Off/On)
p3: Type (DI-1,DO-1, DO-2, DIO-11, DIO-12,
DO-2P, DIO-12P)
Set to DIO-12 or DIO-2P here.
p4: Internal switch number (SW001-SW036, or
SW001-SW018 for the CX1000)
p5: ON DO number (DI001-DI006, DI101-
DI106, DI201-DI206, RI001-RI012, or
DI001-DI006 for the CX1000)
p6: OFF DO number (DI001-DI006, DI101-
DI106, DI201-DI206, RI001-RI012, or
DI001-DI006 for the CX1000)
p7: DI number (DI001-DI006, DI101-DI106,
DI201-DI206, RI001-RI012, or DI001-DI006
for the CX1000)
Query
DX p1?
Example
Set DIO operation monitoring number 2 so that
the ON status of internal switch SW003 is output
from DO002, the OFF status is output from
DO003, and DIO02's status is monitored.
DX2,ON,DIO-12,SW003,DO002,DO003,
DI002
Description With DO-2, DO-2P, DIO-12, and DIO-12P, ON
DO and OFF DO cannot be set to the same DO.
DY
Sets the DIO operation
monitoring function tag and tag
comment
Syntax
DX p1,p2,p3
p1: DIO operation monitoring function number
(01–36, 01–12 for the CX1000)
p2: Tag (8 alphanumeric characters, no
symbols)
p3: Tag comment (8 alphanumeric characters,
no symbols)
Query
DX[ p1]?
Example
Set DIO operation monitoring function number
3’s tag to test, and the tag comment to onoff.
DX3,test,onoff
DZ
Sets the DIO operation
monitoring function label and
display color
Syntax
DZ p1,p2,p3,p4,p5
p1: DIO operation monitoring function number
(01–36, 01–12 for the CX1000)
p2: ON label (8 alphanumeric characters, no
symbols)
p3: ON display color
Red, Green, B.violet, Brown, Orange,
Y.green, Lightblue, Violet, Lime, Cyan,
Darkblue, Purple
p4: OFF label (8 alphanumeric characters, no
symbols)
p5: OFF display color
Red, Green, B.violet, Brown, Orange,
Y.green, Lightblue, Violet, Lime, Cyan,
Darkblue, Purple
Query
DZ[ p1]?
Example
Set DIO operation monitoring function number
3’s ON label to start, the ON display color to red,
the OFF label to stop, and the OFF display color
to green.
DZ3,start,Red,stop,Green
