3-12
IM 04L31A01-17E
Selecting the Parity Check
9. Use the arrow keys to move the cursor to the [Parity] box.
10. Press one of the soft keys from [Odd] to [None] to select the parity.
Selecting the Handshaking
(This setting is valid only for the RS-232 interface.)
11. Use the arrow keys to move the cursor to the [Handshaking] box.
12. Press one of the soft keys from [Off:Off] to [CS:RS] to select the handshaking.
Selecting the Address
(This setting is valid for the RS-422/485 interface and the Modbus protocol.)
13. Use the arrow keys to move the cursor to the [Address] box.
14. Press one of the soft keys from [1] to [32] to select the address.
Selecting the Protocol
15. Use the arrow keys to move the cursor to the [Protocol] box.
16. Press one of the soft keys from [Normal] to [Ladder] to select the baud rate.
The display varies depending on the options you specified at the time of
purchase.
or
3.5 Configuring the Serial Interface
