Chapter 4: Operation and Setup Series D8 User’s Guide
78 Watlow Anafaze Doc. 0600-3120-2000
Figure 4.1 General Navigation Map
02 1025∞C
1050auto100
Job 1 running
Job Display (if a job is loaded)
lGlobal setup r
Other menus b
Setup Menus
Scanning Loop Display
01 925 ∞C
1000man 100
02 1025∞C
1000man 100
03 1050∞C
1050auto 0
Loop Display
01 925 ∞C
1000auto100
l01 Set point r
^ 1000
l01 Mode r
^manual
l01 Heat out r
^ 0 %
Operator Parameters
l01 Cool out r
b 0 %
Hold 3 seconds
Same Screen on the
Next or Previous Loop
Hold 3 seconds
><
.
LOOP
