Chapter 6: Menu and Parameter Reference Series D8 User’s Guide
132 Watlow Anafaze Doc. 0600-3120-2000
Loop Name
Enter a two-character name for the loop. This name is shown
on the controller display in place of the loop number.
Values:
See Table 6.8.
Default:
The loop number (01, 02, 03, and so on.)
DeviceNet Object
: Input (64 hex)
Table 6.8 Characters for the Loop Name and
Input Units Parameters
Input Units
For a thermocouple or RTD input, choose the temperature
scale. For a process input, enter a three-character description
of the engineering units.
Values:
For a process input, see Table 6.8. For a thermocou-
ple or RTD input, ˚F or ˚C. When setting the units for a ther-
mocouple or RTD input through communications, you must
set the first character as a space (32), the second character as
the degree symbol (223) and the third character as “C” (67) or
“F” (70).
Default:
˚C for a thermocouple or RTD input, three spaces for
a process input
DeviceNet Object
: Input (64 hex)
Calibration Offset
For a thermocouple or RTD input, enter the offset to correct
for signal inaccuracy. A positive value increases the reading
and a negative value decreases it. Use an independent sensor
or your own calibration equipment to find the offset for your
system.
Values:
See Table 6.9
Default:
0 or 0.0
Character Display Values ASCII Values
A to Z
A to Z
65 to 90
0 to 9
0 to 9
48 to 57
Degree symbol ˚ 223
Percent sign
%
37
Forward slash
/
47
Space
.
32
Pound sign # 35
l01 Loop name r
b01
l01 Input unitsr
b ˚F
l01 Calibrationr
offsetb 0 ˚F
