Series D8 User’s Guide Chapter 6: Menu and Parameter Reference
Doc. 0600-3120-2000 Watlow Anafaze 145
High Deviation Value
Enter the amount by which the process variable must rise
above the set point for the high deviation alarm to occur. For
more information, see Deviation Alarms on page 96.
Values:
See Table 6.12 on page 138 for values and decimal
placement.
Default:
See Table 6.12 .
DeviceNet Object:
Alarm (67 hex)
High Deviation Function
Choose whether the alarm functions as an alarm or as a boost
output, or disable the alarm.
Values:
See Table 6.14 on page 144.
Default:
off
DeviceNet Object:
See Alarm Enable on page 153 and Alarm
Function on page 154.
High Deviation Output
Choose a digital output to activate when the high deviation
alarm occurs. You cannot choose an output that is in use for
closed-loop control or for the Serial DAC clock.
Values:
none (0) or output 1 to 18 (1 to 18). Values in paren-
theses are for communications.
Default:
none (0)
DeviceNet Object:
Alarm (67 hex)
Low Deviation Value
Enter the amount by which the process variable must fall be-
low the set point for the low deviation alarm to occur. For
more information, see Process Alarms on page 95.
Values:
See Table 6.12 on page 138 for values and decimal
placement.
Default:
Table 6.12
DeviceNet Object:
Alarm (67 hex)
Low Deviation Function
Choose whether the alarm functions as an alarm or as a boost
output, or disable the alarm.
Values:
See Table 6.14 on page 144.
Default:
off
DeviceNet Object:
See Alarm Enable on page 153 and Alarm
Function on page 154.
l01 HiDeviationr
value b 5 ˚C
l01 HiDeviationr
func boff
l01 HiDeviationr
outputbnone
l01 LoDeviationr
value b 5 ˚C
l01 LoDeviationr
func boff
