D8 Parts List
You may have received one or more of the following compo-
nents. See Figure 2.1 on page 12 for D8 configuration infor-
mation.
•
D8 series controller with mounting collar and brackets
• TB50 with 50-pin SCSI cable
• Power supply with mounting bracket and screws
• Serial DAC (digital-to-analog converter)
• Special input resistors (installed in D8)
• User’s guide
Figure 1.1 D8 Standard Parts List
D8x0-0000-xx0x
Number of Loops
4 = 4-loop controller
8 = 8-loop controller
Digital I/O Termination
0 = TB18
1 = SCSI connector, no terminal board or cable
2 = SCSI connector, TB50 and 3-foot cable
3 = SCSI connector, TB50 and 6-foot cable
4 = SCSI connector, TB50 and 3-foot right angle cable
5 = SCSI connector, TB50 and 6-foot right angle cable
Power Supply
0 = No power supply
1 = CE Power Supply
2 = Wall mount power supply
Special Inputs
0 = Thermocouples and -10 to 60mV inputs only
X = Number of current, voltage and RTD inputs
