Chapter 3: Communicating by DeviceNet Series D8 User’s Guide
76 Watlow Anafaze Doc. 0600-3120-2000
Table 3.41 Global Instance Attributes
(Instance 1)
* Least significant bit (LSB) is digital input 1, most significant bit (MSB) is digital input 8.
NOTE! All successful explicit message responses
from a Set service will contain no data. The
response will be a two-byte message con-
taining the requester’s node address and
service code (with R/R bit set).
Attribute Access Name Type Description
100 (64 hex) Get/Set Load Setup From Job USINT See page 125.
101 (65 hex) Get/Set Save Setup As Job USINT See page 125.
102 (66 hex) Get/Set BCD Job Load USINT See page 126.
103 (67 hex) Get/Set BCD Job Load Logic BOOL See page 126.
104 (68 hex) Get/Set Mode Override USINT See page 127.
105 (69 hex) Get/Set Mode Override Digital Input Active BOOL See page 128.
106 (6A hex) Get/Set Power Up Alarm Delay USINT See page 128.
107 (6B hex) Get/Set Power Up Loop Mode BOOL See page 128.
108 (6C hex) Get/Set Keypad Lock BOOL See page 129.
109 (6D hex) Get/Set Thermocouple Short Alarm USINT See page 129.
110 (6E hex) Get/Set AC Line Frequency BOOL See page 129.
111 (6F hex) Get/Set Digital Output Alarm Polarity BOOL See page 129.
112 (70 hex) Get Digital Inputs 1 (LSB) to 8 (MSB)* USINT See page 152.
113 (71 hex) Get/Set Digital Outputs 1 (LSB) to 8 (MSB) USINT See page 153.
114 (72 hex) Get/Set Digital Outputs 9 (LSB) to 16 (MSB) USINT See page 153.
115 (73 hex) Get/Set Digital Outputs 17 (LSB) to 18 USINT See page 153.
116 (74 hex) Get Ambient Sensor INT See page 155.
117 (75 hex) Get Battery Status BOOL OK = 0; Fault = 1
118 (76 hex) Get HW Ambient Status BOOL OK = 0; Fault = 1
119 (77 hex) Get HW Offset Status BOOL OK = 0; Fault = 1
120 (78 hex) Get HW Gain Status BOOL OK = 0; Fault = 1
