Series D8 User’s Guide Chapter 6: Menu and Parameter Reference
Doc. 0600-3120-2000 Watlow Anafaze 125
Global Setup Menu
Use the Global setup menu to set parameters that affect all
loops.
Load Setup From Job
Load one of the jobs stored in battery-backed RAM. The fol-
lowing parameters are loaded for each loop as part of a job:
•
PID constants, filter settings, set points and hysteresis.
• Control mode (automatic or manual) and output power
levels (if the loop is in manual control)
• Alarm functions, set points, hysteresis and delay settings.
If you have enabled remote job selection (see BCD Job Load
on page 126), you will see the message below, and you will
not be able to use the controller keypad to load a job.
NOTE! Current settings are overwritten when you
select a job from memory. Save your current
settings to another job number if you want to
keep them.
Values:
1 to 8 (1 to 8) or none (0). Values in parentheses are
for communications.
Default:
none (0)
DeviceNet Object
: Global (6B hex)
Save Setup As Job
Save the current settings as one of eight jobs in the battery-
backed RAM. The following parameters are saved for each
loop as part of a job:
•
PID constants, filter settings, set points and hysteresis.
• Control mode (automatic, tune, off or manual) and output
power levels (if the loop is in manual control)
• Alarm functions, set points, hysteresis and delay settings.
lGlobal setup r
Other menus b
lLoad setup r
from job bnone
lLoad setup r
not available
lSave setup as r
job bnone
