Series D8 User’s Guide Chapter 6: Menu and Parameter Reference
Doc. 0600-3120-2000 Watlow Anafaze 123
Process Variable
Indicates the value measured by the sensor after filtering and
scaling. This parameter is read-only.
Values:
For thermocouples and RTD inputs, same as the input
range (see Table 6.7 on page 131). For process and pulse in-
puts, any value between the Input range low and Input range
high
parameters in the Input menu.
Decimal Placement for DeviceNet:
See Decimal Placement
for Numeric Values on page 59.
DeviceNet Object:
Assembly (04 hex), Input (64 hex)
Overview of the Setup Menus
The D8 has nine setup menus. Table 6.2 provides a brief de-
scription of each menu. Figure 6.2 lists all of the menus and
parameters in the same order that they appear in the controller.
Table 6.2 D8 Setup Menus
Menu Description
Page
Number
Global setup Configure global settings, which affect all loops. 125
Input Configure the input for each loop. 131
Control Configure PID control for each loop. 136
Output Configure heat and cool outputs for each loop. 139
Alarms Configure alarms for each loop. 143
PV retrans Configure process variable retransmit. 148
Cascade Configure cascade control. 149
Ratio Configure ratio control. 150
I/O test Perform tests of the digital inputs, digital outputs and keypad. 151
01 925 ˚F 0
1000man 100
