Menu structure, Menu structure 213 – Watlow Series D8 User Manual

Page 231

Doc. 0600-3120-2000

Watlow Anafaze

213

Menu Structure

Global setup

Load setup from job
Save setup as job
BCD job load
BCD job load logic
Mode override
Mode override D/I active
Power up alarm delay
Power up loop mode
Keypad lock
TC short alarm
AC line freq
D/O alarm polarity
MAC ID
Baud rate
Module LED
Network LED
Bus off count
WATLOW D8x Vx.xx cs=xxxx

Input

(page 131)

Input type
Loop name
Input units
Input pulse sample
Calibration offset
Reversed T/C detect
Disp format
Input range high
Input high signal
Input range low
Input low signal
Input filter

Control

(page 136)

Heat prop band

Heat integral
Heat derivative
Heat manual reset
Heat filter
Cool prop band
Cool integral
Cool derivative
Cool manual reset
Cool filter
Hysteresis
RestoreAuto

Output

(page 139)

Heat output type

Heat cycle time
Heat SDAC signal
Ht SDAC low signal
Ht SDAC hi signal
Heat action
Heat power limit
HtPwr limit time
Sensor fail heat output
Open T/C ht out average
Heat output curve
Cool output type
Cool cycle time
Cool SDAC signal
Cl SDAC low signal
Cl SDAC hi signal
Cool action
Cool power limit
ClPwr limit time
Sensor fail cool output
Open T/C cl out average
Cool output curve

Alarms

(page 143)

Alarm high SP

Alarm high func
Alarm high output
HiDeviation value
HiDeviation func
HiDeviation output
LoDeviation value
LoDeviation func
LoDeviation output
Alarm low SP
Alarm low func
Alarm low output
Alarm hysteresis
Alarm delay

PV retrans

(page 148)

Heat output retrans PV

Ht retrans LowPV
Ht retrans HighPV
Cool output retrans PV
Cl retrans LowPV
Cl retrans HighPV

Cascade

(page 149)

Cascade prim loop

Cascade low SP
Cascade hi SP

Ratio

(page 150)

Ratio master loop

Ratio low SP
Ratio high SP
Control ratio
Ratio SP diff
