Series D8 User’s Guide
Chapter 2: Installation
Doc. 0600-3120-2000
Watlow Anafaze
37
TB50 Connections
Table 2.7
TB50 Connections
1
The indicated outputs are dedicated for control when enabled in the
loop setup. If one or both of a loop’s outputs are disabled, the corre-
sponding digital outputs become available for alarms or programmable
logic.
2
If you install a Watlow Anafaze Serial DAC, the D8 uses digital output
18 (terminal 42) for a clock line. You cannot use output 18 for anything
else if a Serial DAC is installed.
Control Output
1
Control Output
1
Ter-
minal
Function
D88
D84
Ter-
minal
Function
D88
D84
1
+5 Vdc
2
+5 Vdc
3
CTRL COM
4
CTRL COM
5
Not used
6
Watchdog
Timer
7
Not used
8
Global Alarm
9
Output 1
Loop 1 heat
Loop 1 heat
10
Not used
11
Output 2
Loop 2 heat
Loop 2 heat
12
Not used
13
Output 3
Loop 3 heat
Loop 3 heat
14
Not used
15
Output 4
Loop 4 heat
Loop 4 heat
16
Not used
17
Output 5
Loop 5 heat
Loop 1 cool
18
Not used
19
Output 6
Loop 6 heat
Loop 2 cool
20
Not used
21
Output 7
Loop 7 heat
Loop 3 cool
22
Not used
23
Output 8
Loop 8 heat
Loop 4 cool
24
Not used
25
Output 9
Loop 1 cool
26
Not used
27
Output 10
Loop 2 cool
28
Not used
29
Output 11
Loop 3 cool
30
Not used
31
Output 12
Loop 4 cool
32
Not used
33
Output 13
Loop 5 cool
34
Not used
35
Output 14
Loop 6 cool
36
Not used
37
Output 15
Loop 7 cool
38
Not used
39
Output 16
Loop 8 cool
40
Not used
41
Output 17
42
Output 18
2
Serial
DAC clock
43
Input 1
44
Input 2
45
Input 3
46
Input 4
47
Input 5
48
Input 6
49
Input 7
50
Input 8
