Series D8 User’s Guide

Chapter 6: Menu and Parameter Reference

Doc. 0600-3120-2000

Watlow Anafaze

131

Model and Firmware Version

The last parameter in the Global setup menu shows the con-

troller model (WATLOW D84 or WATLOW D88), the firm-

ware version (Vxx.xx), and the flash-memory checksum

(CS=xxxx).

DeviceNet Objects

: Model: Identity (01 hex), Firmware Ver-

sion: N/A, Checksum: N/A.

Input Menu

Use the Input menu to configure the process input:

Input type

Engineering units

Scaling, calibration and filtering.

Input Type

Choose the type of sensor that is connected to the analog input.

Values:

See Table 6.7.

Default:

J thermocouple (1)

DeviceNet Object

: Input (64 hex)

Table 6.7

Input Types and Ranges

Display

Value

DeviceNet

Value

Description

Input Range

J t/c

1

Type J thermocouple

-350 to 1400°F (-212 to 760°C)

K t/c

2

Type K thermocouple

-450 to 2500° F (-268 to 1371°C)

T t/c

3

Type T thermocouple

-450 to 750°F (-268 to 399°C)

S v

4

Type S thermocouple

0 to 3200°F (-18 to 1760°C)

R t/c

5

Type R thermocouple

0 to 3210°F (-18 to 1766°C)

B t/c

6

Type B thermocouple

150 to 3200°F (66 to 1760°C)

E t/c

20

Type E thermocouple

-328 to 1448°F (-200 to 787°C)

RTD

8

RTD

-328.0 to 1150.0°F (-200.0 to 621.1°C)

process

0

Voltage or current signal,

depending upon the hardware

configuration. See Figure 1.2 on

page 6.

User defined. See Setting Up Pro-

cess Variable Retransmit on page

97.

skip

10

Loop is not used for control, does

not report alarms, and is not

shown on the scanning display.

(none)

lWATLOW D84 r
V1.00 cs=1234

l01 Input r
Other menus b

l01 Input type r
bJ T/C
