Series D8 User’s Guide Chapter 3: Communicating by DeviceNet
Doc. 0600-3120-2000 Watlow Anafaze 69
Table 3.22 Output Class Attributes (Instance 0)
Table 3.23 Output Instance Attributes
(Instances 1 to 4 or 8)
Attribute Access Name Type Description
1 (1 hex) Get Revision UINT Revision of this object
2 (2 hex) Get Max Instance UINT Maximum instances of this object (8)
3 (3 hex) Get
Number of
Instances
UINT Number of object instances
Attribute Access Name Type Description
100 (64 hex) Get/Set Heat Output UINT See page 122.
101 (65 hex) Get/Set Cool Output UINT See page 122.
102 (66 hex) Get/Set Heat Output Type USINT See page 139.
103 (67 hex) Get/Set Cool Output Type USINT See page 139.
104 (68 hex) Get/Set Heat Action BOOL See page 141.
105 (69 hex) Get/Set Cool Action BOOL See page 141.
106 (6A hex) Get/Set Heat Cycle Time USINT See page 140.
107 (6B hex) Get/Set Cool Cycle Time USINT See page 140.
108 (6C hex) Get/Set Heat Power Limit UINT See page 141.
109 (6D hex) Get/Set Cool Power Limit UINT See page 141.
110 (6E hex) Get/Set Heat Power Limit Time UINT See page 141.
111 (6F hex) Get/Set Cool Power Limit Time UINT See page 141.
112 (70 hex) Get/Set Sensor Fail Heat Output UINT See page 142.
113 (71 hex) Get/Set Sensor Fail Cool Output UINT See page 142.
114 (72 hex) Get/Set
Open Thermocouple Heat
Output Average
BOOL See page 142.
115 (73 hex) Get/Set
Open Thermocouple Cool
Output Average
BOOL See page 142.
116 (74 hex) Get/Set Heat Output Curve USINT See page 143.
117 (75 hex) Get/Set Cool Output Curve USINT See page 143.
118 (76 hex) Get/Set Heat SDAC Signal BOOL See page 140.
119 (77 hex) Get/Set Cool SDAC Signal BOOL See page 140.
120 (78 hex) Get/Set Heat SDAC Low Signal UINT See page 140.
121 (79 hex) Get/Set Cool SDAC Low Signal UINT See page 140.
122 (7A hex) Get/Set Heat SDAC High Signal UINT See page 140.
123 (7B hex) Get/Set Cool SDAC High Signal UINT See page 140.
124 (7C hex) Get/Set
Heat/Cool Output Action for
Watchdog Inactivity Fault
BOOL See page 156.
