Chapter 8: Specifications

Series D8 User’s Guide

194

Watlow Anafaze

Doc. 0600-3120-2000

Table 8.29

Serial DAC Agency Approvals /
Compliance

Serial DAC Inputs

The Serial DAC requires a proprietary serial data signal and

the clock signal from the D8 via the TB50. Any control output

can be configured to provide the data signal. The Serial DAC

also requires a 5 Vdc power input.

Table 8.30

Serial DAC Inputs

Table 8.31

Serial DAC Power Requirements

CE Directive

Electromagnetic Compatibility (EMC)

directive 89/336/EEC

UL and C-UL

UL 916 Standard for Energy Manage-

ment Equipment File E177240

Data

4 mA maximum to DC COM

Open collector or HC CMOS logic levels

Clock

0.5 mA maximum to DC COM

Open collector or HC CMOS logic levels

Voltage

4.75 to 5.25 Vdc @ 300 mA maximum
