Chapter 8: Specifications

Series D8 User’s Guide

192

Watlow Anafaze

Doc. 0600-3120-2000

Dual DAC Inputs

The Dual DAC accepts an open-collector signal from the D8

controller and the power from an external power supply. See

Table 8.25 .

Table 8.25

Dual DAC Power Requirements

Dual DAC Analog Outputs

Table 8.26

Dual DAC Specifications by Output
Range

Parameter

Description

Voltage

12 to 24 Vdc

Current

100 mA @ 15 Vdc

Version

4 to 20 mA

0 to 5 V

0 to 10 V

Units

Gain Accuracy

percent

Output Offset

0.75

percent of full

scale range

Ripple

1.6

percent of full

scale range

Time Constant

seconds

Maximum Current Output

mAdc

Load Resistance (12 V)

250 maximum

500 minimum

1000 minimum

Ohms

Load Resistance (24 V)

850 maximum

n/a

Ohms
