Chapter 6: Menu and Parameter Reference Series D8 User’s Guide
126 Watlow Anafaze Doc. 0600-3120-2000
If you have enabled remote job selection (see BCD Job Load
on page 126), you will see the message below, and you will
not be able to use the controller keypad to save a job.
Values:
1 to 8 (1 to 8) or none (0). Values in parentheses are
for communications.
Default:
none (0)
DeviceNet Object:
Global (6B hex)
BCD Job Load
Choose the digital input(s) to use for remote job selection. The
controller uses the states of the selected inputs as a binary
code that specifies which job number to run (see Table 6.3).
To save jobs into memory, use the Save setup as job parame-
ter.
Values:
See Table 6.3
Default:
disabled (0)
DeviceNet Object
: Global (6B hex)
Table 6.3 Values for BCD Job Load
BCD Job Load Logic
Choose which state is considered “true” for the digital inputs
that are used for remote job selection.
•
If 1=true is selected, then an input is true if connected to
controller common, and false for an open circuit.
• If 0=true is selected, then an input is true for an open cir-
cuit, and false if connected to controller common.
Table 6.4 shows which combinations of input states are re-
quired to load each job.
Display
Value
DeviceNet
Value
Description
use D/I 1
1 Use digital input 1 for remote selection of jobs 1 and 2.
use D/I 1-2
2 Use digital inputs 1 and 2 for remote selection of jobs 1 to 4.
use D/I 1-3 3 Use digital inputs 1 to 3 for remote selection of jobs 1 to 8.
disabled
0 Disable remote job selection
lSave setup as r
not available
lBCD job load r
bdisabled
lBCD job load r
logic b1=true
