Normal conditions
Error conditions
Event
LED1
LED2
Camera startup
During startup all LEDs are switched on consecu-
tively to show the startup progress:
Phase1:
LED1 RED
Phase2:
LED1 RED
+
LED1 GREEN
Phase3:
LED1 RED
+
LED1 GREEN
+
LED2 RED
Phase4:
LED1 RED
+
LED1 GREEN
+
LED2 RED
+
LED2 GREEN
Power on
GREEN
Bus reset
GREEN blinking
Asynchronous traffic
+GREEN pulsing
GREEN
Only GOF:
asynchronous traffic
+GREEN pulsing
(inverted)
GREEN
Only GOF:
GOF signal detect
GREEN
GREEN
Isochronous traffic
+RED pulsing
GREEN
Waiting for external
trigger
RED
GREEN
External trigger event
RED
+RED pulsing
Table 20: LEDs showing normal conditions
LED1 RED
LED2 GREEN
Warning
1 pulse
DCAM
2 pulse
MISC
3 pulse
FPGA
4 pulse
Stack
5 pulse
FPGA boot error
1-5 pulse
Stack setup
1 pulse
Stack start
2 pulse
No FLASH object
1 pulse
No DCAM object
1 pulse
Register mapping
3 pulse
VMode_ERROR_STATUS
1 pulse
FORMAT_7_ERROR_1
2 pulse
FORMAT_7_ERROR_2
3 pulse
Table 21: Error codes
