Configuration of the camera
STINGRAY Technical Manual V4.4.4
292
Advanced features (AVT-specific)
The camera has a variety of extended features going beyond the possibilities
described in IIDC V1.31. The following chapter summarizes all available (AVT-
specific) advanced features in ascending register order.
Advanced registers summary
The following table gives an overview of all available advanced registers:
Note

This chapter is a reference guide for advanced registers
and does not explain the advanced features itself.
For detailed description of the theoretical background
see
• Chapter Description of the data path on page 115
• Links given in the table below
Register Register name Description
0xF1000010 VERSION_INFO1 See Table 128: Advanced register: Extended ver-
sion information on page 296
0xF1000014 VERSION_INFO1_EX
0xF1000018 VERSION_INFO3
0xF100001C VERSION_INFO3_EX
0xF1000040 ADV_INQ_1 See Table 130: Advanced register: Advanced fea-
ture inquiry on page 298
In ADV_INQ_3 there is a new field
F7MODE_MAPPING [3]

Low Noise Binning [9]
0xF1000044 ADV_INQ_2
0xF1000048 ADV_INQ_3
0xF100004C ADV_INQ_4
0xF1000100 CAMERA_STATUS See Table 131: Advanced register: Camera status
on page 300
0xF1000200 MAX_RESOLUTION See Table 132: Advanced register: Maximum res-
olution inquiry on page 301
0xF1000208 TIMEBASE See Table 133: Advanced register: Time base on
page 301
0xF100020C EXTD_SHUTTER See Table 135: Advanced register: Extended
shutter on page 303
0xF1000210 TEST_IMAGE See Table 136: Advanced register: Test images
on page 304
0xF1000220 SEQUENCE_CTRL See Table 73: Advanced register: Sequence mode
on page 204
0xF1000224 SEQUENCE_PARAM
0xF1000228 SEQUENCE_STEP
Table 127: Advanced registers summary
