Description of the data path
STINGRAY Technical Manual V4.4.4
128
The following table shows the BRIGHTNESS register:
Register Name Field Bit Description
0xF0F00800 BRIGHTNESS Presence_Inq [0] Presence of this feature:

0: N/A

1: Available
Abs_Control [1] Absolute value control

O: Control with value in the value field

1: Control with value in the absolute
value CSR

If this bit= 1 the value in the value field
has to be ignored
--- [2..4] Reserved
One_Push [5] Write: Set bit high to start

Read: Status of the feature:
Bit high: WIP
Bit low: Ready
ON_OFF [6] Write: ON or OFF this feature
Read: read a status
0: OFF

1: ON
A_M_MODE [7] Write: set mode

Read: read current mode
0: MANUAL

1: AUTO
--- [8..19] Reserved
Value [20..31] Read/Write Value; this field is ignored
when writing the value in Auto or OFF
mode; if readout capability is not avail-
able reading this field has no meaning.
Table 45: CSR: Brightness
