Video formats, modes and bandwidth
STINGRAY Technical Manual V4.4.4
215
Stingray F-033B / Stingray F-033C

and board level F-033B BL / F-033C BL
Table 76: Video fixed formats Stingray F-033B / F-033C
Format Mode Resolution Color mode 240
fps
120
fps 60
fps 30
fps 15
fps 7.5
fps 3.75
fps 1.875
fps
0
0 160 x 120 YUV444
1 320 x 240 YUV422 x x x x x x
2 640 x 480 YUV411 x x x x x x
3 640 x 480 YUV422 x x x x x x
4 640 x 480 RGB8 x x x x x x
5 640 x 480 Mono8 x x* x x* x x* x x* x x* x x*
6 640 x 480 Mono16 x x x x x x
* : Color camera outputs Mono8 interpolated image.
Frame rates with shading are only achievable with 1394b (S800).
Note

The following table shows default Format_7 modes with-
out Format_7 mode mapping.
For information on Format_7 mode mapping ...
• ... see Chapter Mapping of possible Format_7 modes to
F7M1...F7M7 on page 160
• ... see Chapter Format_7 mode mapping on page 327
