Introduction

STINGRAY Technical Manual V4.4.4

16

continued from last page

V3.0.0

08.10.08

New Stingray board level CAD drawing with name of screws
M2x14 ISO7045-A2 (2x):

Figure 38: Stingray board level: CS-Mount

on page 87

Figure 39: Stingray board level: C-Mount

on page 88

New Stingray F-125B/C: Read information in the following sec-
tions:

Table 14: Specification STINGRAY F-125B/C (fiber)

on page

52f.

Table 54: FIFO memory size

on page 169

Table 65: Camera-specific exposure time offset

on page 194

Table 66: Camera-specific minimum exposure time

on page

194

Figure 99: Data flow and timing after end of exposure

on

page 199

Table 71: Jitter at exposure start (no binning, no sub-sam-
pling)

on page 202

Table 82: Video fixed formats Stingray F-125B / F-125C

on

page 221

Table 83: Video Format_7 default modes Stingray F-125B /
F-125C

on page 222

Table 129: Camera type ID list

on page 297

For Stingray F-125B/C output switching times (tp and min.
shutter) see Hardware Installation Guide, subsection
STINGRAY delay

to be continued on next page

Version

Date

Remarks

Table 1: Document history
