Description of the data path
STINGRAY Technical Manual V4.4.4
153
Figure 77: Horizontal sub-sampling 2 out of 4 (b/w)
Figure 78: Horizontal sub-sampling 2 out of 8 (b/w)
Figure 79: Horizontal sub-sampling 2 out of 4 (color)
Figure 80: Horizontal sub-sampling 2 out of 8 (color)
2 out of 4
2 out of 8
only F-145,
F-146, F-201
2 out of 4
2 out of 8
only F-145,
F-146, F-201,
F504C
