Description of the data path
STINGRAY Technical Manual V4.4.4
174
In color interpolation a red, green or blue value is determined for each pixel.
Only two lines are needed for this interpolation:
Figure 92: BAYER demosaicing (interpolation)
Formula 4: BAYER demosaicing
Note
Please note that on the color camera, a wrongly colored
border of one or two pixel wide forms on the left and right
image borders. This is also a consequence of BAYER dem-
osaicing as the image width displayed on the color camera
is not scaled down.
P1
red
R1
=
P1
green
G1
G3
+
2
------------------
=
P1
blue
B1
=
P2
red
R2
=
P2
green
G1
G4
+
2
------------------
=
P2
blue
B1
=
P3
red
R2
=
P3
green
G2
G4
+
2
------------------
=
P3
blue
B2
=
