Description of the data path
STINGRAY Technical Manual V4.4.4
123
To configure this feature in control and status register (CSR):
Register Name Field Bit Description
0xF0F0081C SHUTTER Presence_Inq [0] Presence of this feature:

0: N/A

1: Available
Abs_Control [1] Absolute value control

O: Control with value in the Value field

1: Control with value in the Absolute value
CSR

If this bit=1, the value in the Value field will
be ignored.
--- [2..4] Reserved
One_Push [5] Write 1: begin to work (self-cleared after oper-
ation)

Read:

1: in operation

0: not in operation

If A_M_Mode = 1, this bit will be ignored.
ON_OFF [6] Write: ON or OFF this feature

Read: read a status

0: OFF

1: ON
A_M_MODE [7] Write: set mode

Read: read current mode

0: MANUAL

1: AUTO
--- [8..19] Reserved
Value [20..31] Read/Write Value
This field is ignored when writing the value in
Auto or OFF mode.

If readout capability is not available, reading
this field has no meaning.
Table 41: CSR: Shutter
Note

Configuration
To configure this feature in an advanced register: See
Table 144: Advanced register: Auto shutter control on page
315.
