Video formats, modes and bandwidth
STINGRAY Technical Manual V4.4.4
222
Format Mode Resolution Color mode Maximal S800 frame rates for Format_7 modes
7 0 1292 x 964


1292 x 964
Mono8

Mono12

Mono16
YUV411

YUV422,Raw16

Mono8,Raw8

RGB8

Raw12
30 fps

30 fps

26 fps
30 fps

26 fps

30 fps

17 fps

30 fps
1 644 x 964 Mono8

Mono12

Mono16
30 fps 2x H-binning

30 fps 2x H-binning

30 fps 2x H-binning
2 1292 x 482 Mono8

Mono12

Mono16
53 fps 2x V-binning

53 fps 2x V-binning

52 fps 2x V-binning
3 644 x 482 Mono8

Mono12

Mono16
53 fps 2x H+V binning

53 fps 2x H+V binning

53 fps 2x H+V binning
4 644 x 964


644 x 964
Mono8

Mono12

Mono16
YUV411

YUV422,Raw16

Mono8,Raw8

RGB8

Raw12
30 fps 2 out of 4 H-sub-sampling

30 fps 2 out of 4 H-sub-sampling

30 fps 2 out of 4 H-sub-sampling
30 fps 2 out of 4 H-sub-sampling

30 fps 2 out of 4 H-sub-sampling

30 fps 2 out of 4 H-sub-sampling

30 fps 2 out of 4 H-sub-sampling

30 fps 2 out of 4 H-sub-sampling
5
# 1292 x 482


1292 x 482
Mono8

Mono12

Mono16
YUV411

YUV422,Raw16

Mono8,Raw8

RGB8

Raw12
30 fps 2 out of 4 V-sub-sampling

30 fps 2 out of 4 V-sub-sampling

30 fps 2 out of 4 V-sub-sampling
30 fps 2 out of 4 V-sub-sampling

30 fps 2 out of 4 V-sub-sampling

30 fps 2 out of 4 V-sub-sampling

30 fps 2 out of 4 V-sub-sampling

30 fps 2 out of 4 V-sub-sampling
6
# 644 x 964


644 x 482
Mono8

Mono12

Mono16
YUV411

YUV422,Raw16

Mono8,Raw8

RGB8

Raw12
30 fps 2 out of 4 H+V-sub-sampling

30 fps 2 out of 4 H+V-sub-sampling

30 fps 2 out of 4 H+V-sub-sampling
30 fps 2 out of 4 H+V-sub-sampling

30 fps 2 out of 4 H+V-sub-sampling

30 fps 2 out of 4 H+V-sub-sampling

30 fps 2 out of 4 H+V-sub-sampling

30 fps 2 out of 4 H+V sub-sampling
Table 83: Video Format_7 default modes Stingray F-125B / F-125C
