Configuration of the camera

STINGRAY Technical Manual V4.4.4

313

Input/output pin control

0xF100029C

DPC_MEM

Presence_Inq

[0]

Indicates presence of this
feature (read only)

---

[1]

Reserved

EnaMemWR

[2]

Enable write access from host
to RAM

EnaMemRD

[3]

Enable read access from RAM
to host

DPDataSize

[4..17]

Size of defect pixel data to
read from RAM to host.

A maximum of 256 defect pix-
els can be stored. In case of
more than 256 defect pixels,
DPDataSize is set to 257 and
BuildError flag is set to 1.

Defect pixel correction data is
done with first 256 defect
pixels only.

AddrOffset

[18..31] Address offset to selected

defect pixel data

0xF10002A0

DPC_INFO

Presence_Inq

[0]

Indicates presence of this
feature (read only)

---

[1..3]

Reserved

MinThreshold

[4..10]

Minimum value for threshold

MaxThreshold

[11..17] Maximum value for threshold

MaxSize

[18..31] Maximum size of defect pixel

data

Note

See Chapter

Input/output pin control

on page 97

See Chapter

IO_INP_CTRL 1-2

on page 98

See Chapter

IO_OUTP_CTRL 1-4

on page 103

See Chapter

Output modes

on page 104

Register

Name

Field

Bit

Description

Table 142: Advanced register: Defect pixel correction
