Video formats, modes and bandwidth
STINGRAY Technical Manual V4.4.4
216
Format Mode Resolution Color mode Maximal S800 frame rates for Format_7 modes
7
0 656 x 492


656 x 492
Mono8

Mono12

Mono16
YUV411

YUV422,Raw16

Mono8,Raw8

RGB8

Raw12
84 fps

84 fps

84 fps
84 fps

84 fps

84 fps

67 fps

84 fps
1 328 x 492 Mono8

Mono12

Mono16
84 fps 2x H-binning

84 fps 2x H-binning

84 fps 2x H-binning
2 656 x 246 Mono8

Mono12

Mono16
149 fps 2x V-binning

149 fps 2x V-binning

149 fps 2x V-binning
3 328 x 246 Mono8

Mono12

Mono16
149 fps 2x H+V binning

149 fps 2x H+V binning

149 fps 2x H+V binning
4 328 x 492


328 x 492
Mono8

Mono12

Mono16
YUV411

YUV422,Raw16

Mono8,Raw8

RGB8

Raw12
84 fps 2 out of 4 H-sub-sampling

84 fps 2 out of 4 H-sub-sampling

84 fps 2 out of 4 H-sub-sampling
84 fps 2 out of 4 H-sub-sampling

84 fps 2 out of 4 H-sub-sampling

84 fps 2 out of 4 H-sub-sampling

84 fps 2 out of 4 H-sub-sampling

84 fps 2 out of 4 H-sub-sampling
5 656 x 246


656 x 246
Mono8

Mono12

Mono16
YUV411

YUV422,Raw16

Mono8,Raw8

RGB8

Raw12
108 fps 2 out of 4 V-sub-sampling

108 fps 2 out of 4 V-sub-sampling

108 fps 2 out of 4 V-sub-sampling
108 fps 2 out of 4 V-sub-sampling

108 fps 2 out of 4 V-sub-sampling

108 fps 2 out of 4 V-sub-sampling

108 fps 2 out of 4 V-sub-sampling

108 fps 2 out of 4 V-sub-sampling
6 328 x 246


328 x 246
Mono8

Mono12

Mono16
YUV411

YUV422,Raw16

Mono8,Raw8

RGB8

Raw12
108 fps 2 out of 4 H+V sub-sampling

108 fps 2 out of 4 H+V sub-sampling

108 fps 2 out of 4 H+V sub-sampling
108 fps 2 out of 4 H+V sub-sampling

108 fps 2 out of 4 H+V sub-sampling

108 fps 2 out of 4 H+V sub-sampling

108 fps 2 out of 4 H+V sub-sampling

108 fps 2 out of 4 H+V sub-sampling
Table 77: Video Format_7 default modes Stingray F-033B / Stingray F-033C
