Camera dimensions
STINGRAY Technical Manual V4.4.4
79
Stingray W270 (2 x 1394b copper)
This version has the sensor tilted by 270 degrees clockwise, so that it views
downwards.
Figure 30: Stingray W270 (2 x 1394b copper)
Stingray W270 (2x IEEE 1394b)
92.3 x 44 x 38.1 (L x W x H)
2
6
32.8
86
92.3
55.5
44
2
9
3
8
.1
50
1
3
M3 x3 (3x)
