Description of the data path

STINGRAY Technical Manual V4.4.4

141

Building defect pixel correction image in
Format_7 modes

horizontal

Binning/sub-sampling is always done after defect pixel correction. Defect
pixel correction is always done on full horizontal resolution. Therefore defect
pixel detection has always to be done in full horizontal resolution.

vertical

Binning/sub-sampling is done in the sensor, before defect pixel correction.
Therefore defect pixel detection has to be done in the correct vertical
resolution
.

First example

4 x horizontal binning, 2 x vertical binning

 detect defect pixels with 0 x horizontal binning and 2 x vertical binning

Second example

2 out of 8 horizontal sub-sampling, 2 out of 8 vertical sub-sampling

 detect defect pixels with 0 x horizontal sub-sampling and 2 out of 8 ver-
tical sub-sampling

Note

Detect defect pixels always with the full horizontal
resolution

(0 x horizontal binning / 0 x horizontal sub-sampling),
but with the desired vertical binning/sub-sampling.
