Introduction

STINGRAY Technical Manual V4.4.4

18

continued from last page

V4.1.0

28.01.09

All advanced registers in 8-digit format beginning with 0xF1...
in Chapter

Advanced features (AVT-specific)

on page 292ff. and

in Chapter

Parameter-List Update

on page 326

New CAD drawings (hexagon socket head cap screw ISO 4762):

Figure 37: Stingray board level dimensions

on page 86

Figure 38: Stingray board level: CS-Mount

on page 87

Figure 39: Stingray board level: C-Mount

on page 88

Figure 41: Board level camera: two IEEE 1394b FireWire
connectors

on page 91

Figure 43: Board level camera: I/O pin assignment

on page

93

SEQUENCE_RESET register moved to SEQUENCE_STEP register
(0xF1000228) in

SEQUENCE_STEP

on page 205 and in

SEQUENCE_STEP

on page 292

Corrected CAD drawing in

Figure 28: Stingray W90 S90 (2 x

1394b copper)

on page 77

Revised Chapter

White balance

on page 117ff

Memory size (Internal FIFO memory) of Stingray F-125 is 12
frames in

Table 14: Specification STINGRAY F-125B/C (fiber)

on

page 52 and in

Table 54: FIFO memory size

on page 169

Revised

Table 99: Frame rates (fps) Stingray F-125 as function

of AOI height (pixel) [width=1292]

on page 248

Corrected black level increments in Chapter

Brightness (black

level or offset)

on page 127

New AOI frame rates of Stingray F-504 in Chapter

Frame rates

of Stingray F-504 as function of AOI height [width=2452]

on

page 252

New Stingray F-125C RGB8 modes in

Table 82: Video fixed for-

mats Stingray F-125B / F-125C

on page 221

New Stingray F-504C RGB8 modes in

Table 90: Video fixed for-

mats Stingray F-504B / F-504C

on page 234

to be continued on next page

Version

Date

Remarks

Table 1: Document history
