Video formats, modes and bandwidth
STINGRAY Technical Manual V4.4.4
238
• The time for reading the image from the sensor and transporting it into
the FRAME_BUFFER
• The time for transferring the image over the FireWire‚Ñ¢ bus
• The length of the exposure time.
Autofunction AOI
Use this feature to select the image area (work area) on which the following
autofunctions work:
• Auto shutter
• Auto gain
• Auto white balance
In the following screenshot you can see an example of the autofunction AOI:
Figure 105: Example of autofunction AOI (Show work area is on)
Work area
