Camera interfaces
STINGRAY Technical Manual V4.4.4
112
Each component has 8-bit data.
Y
(K+0)
[11..4] Y
(K+1)
[3..0]
Y
(K+0)
[3..0]
Y
(K+1)
[11..4] Y
(K+2)
[11..4]
Y
(K+3)
[3..0]
Y
(K+2)
[3..0]
Y
(K+3)
[11..4] Y
(K+4)
[11..4] Y
(K+5)
[3..0]
Y
(K+4)
[3..0]
Y
(K+5)
[11..4] Y
(K+6)
[11..4] Y
(K+7)
[3..0]
Y
(K+6)
[3..0]
Y
(K+7)
[11..4]
Table 37: Packed 12-Bit Mode (mono and raw) Y12 format (AVT)
R
(K+0)
G
(K+0)
B
(K+0)
R
(K+1)
G
(K+1)
B
(K+1)
R
(K+2)
G
(K+2)
B
(K+2)
R
(K+3)
G
(K+3)
B
(K+3)
R
(K+Pn-4)
G
(K+Pn-4)
B
(K+Pn-4)
R
(K+Pn-3)
G
(K+Pn-3)
B
(K+Pn-3)
R
(K+Pn-2)
G
(K+Pn-2)
B
(K+Pn-2)
R
(K+Pn-1)
G
(K+Pn-1)
B
(K+Pn-1)
Table 38: RGB8 format: Source: IIDC V1.31
