Configuration of the camera
STINGRAY Technical Manual V4.4.4
324
Quick parameter change timing modes
You can choose between the following update timing modes:
•
Standard Parameter Update Timing (slightly modified from previous
Stingray cameras)
•
Quick Format Change Mode
Standard Parameter Update Timing
The camera behaves like older firmware versions without this feature. The
UpdActive flag has no meaning.
Quick Format Change Mode
This mode behaves like Standard Parameter Update Timing mode with the
following exception:
An already started image transport to the host will not be interrupted, but
an already started integration will be interrupted.
Note
For a detailed description see Chapter
Register
Name
Field
Bit
Description
0xF1000570
PARAMUPD_TIMING Presence_Inq
[0]
Indicates presence of this feature
(read only)
---
[1..5]
Reserved
UpdActive
[6]
Update active
see Chapter
0: (default); reset to 0 means
Encapsulated Update end
1: set to 1 means
Encapsulated Update begin
---
[7..23]
Reserved
UpdTiming
[24..31]
Update timing mode
If set to O:
Standard Parameter Update Timing
is active
If set to 2:
Quick Format Change Mode is active
Table 154: Advanced register: Update timing modes
