Cross section: CS-Mount
All Stingray cameras can be delivered with CS-Mount.
Figure 35: Stingray CS-Mount dimension
Note
Pay attention to the maximum sensor size of the applied
CS-Mount lens.
Adjustment spacer
CS-Mount
filter / protection glass
5.1
maximum
protrusion:
1
6
Ш
