Configuration of the camera
STINGRAY Technical Manual V4.4.4
284
Inquiry register for absolute value CSR offset
address
Offset Name Description
700h ABS_CSR_HI_INQ_0 Always 0
704h ABS_CSR_HI_INQ_1 Always 0
708h ABS_CSR_HI_INQ_2 Always 0
70Ch ABS_CSR_HI_INQ_3 Always 0
710h ABS_CSR_HI_INQ_4 Always 0
714h ABS_CSR_HI_INQ_5 Always 0
718h ABS_CSR_HI_INQ_6 Always 0
71Ch ABS_CSR_HI_INQ_7 Always 0
720h ABS_CSR_HI_INQ_8 Always 0
724h ABS_CSR_HI_INQ_9 Always 0
728h ABS_CSR_HI_INQ_10 Always 0
72Ch ABS_CSR_HI_INQ_11 Always 0
730h ABS_CSR_HI_INQ_12 Always 0
734
..
77Fh
Reserved Always 0
780h ABS_CSR_LO_INQ_0 Always 0
784h ABS_CSR_LO_INQ_1 Always 0
788h ABS_CSR_LO_INQ_2 Always 0
78Ch ABS_CSR_LO_INQ_3 Always 0
790h
..
7BFh
Reserved Always 0
7C0h ABS_CSR_LO_INQ_16 Always 0
7C4h ABS_CSR_LO_INQ_17 Always 0
7C8h
..
7FFh
Reserved Always 0
Table 122: Absolute value inquiry register
