Camera interfaces
STINGRAY Technical Manual V4.4.4
114
Y component has 16-bit data. The data type is Unsigned Short (big-endian).
Y component has 12-bit data. The data type is unsigned.
Y Signal level (decimal) Data (hexadecimal)
Highest
Lowest
65535
65534
.
.
1
0
0xFFFF
0xFFFE
.
.
0x0001
0x0000
Figure 51: Data structure of Y(Mono16); Source: IIDC V1.31
Y Signal level (decimal) Data (hexadecimal)
Highest
Lowest
4095
4094
.
.
1
0
0x0FFF
0x0FFE
.
.
0x0001
0x0000
Table 39: Data structure of Packed 12-Bit Mode (mono and raw) (AVT)
