Camera dimensions
STINGRAY Technical Manual V4.4.4
73
STINGRAY (1394b: 1 x GOF, 1 x copper)
Figure 24: Camera dimensions (1394b: 1 x GOF, 1 x copper)
Stingray (1394b: 1x GOF, 1x COP)
73.6 x 44 x 29 (L x W x H)
73.6
66.6
57.5
50
M3x3 (3x)
M3x3 (3x)
M3x4 (2x) 16
1
9
.3
9.7
2
6
13.4
1
3
Q
2
7
9.1 - 0.0
0.3 +
44
2
9
C-Mount
5
.4
