Introduction
STINGRAY Technical Manual V4.4.4
27
• Chapter Video formats, modes and bandwidth on page 214 lists all avail-
able fixed and Format_7 modes (incl. color modes, frame rates, binning/
sub-sampling, AOI=area of interest).
• Chapter How does bandwidth affect the frame rate? on page 253 gives
some considerations on bandwidth details.
• Chapter Configuration of the camera on page 257 lists standard and
advanced register descriptions of all camera features.
• Chapter Firmware update on page 342 explains where to get information
on firmware updates and explains the extended version number scheme
of FPGA/µC.
• Chapter Appendix on page 341 lists the sensor position accuracy of AVT
cameras.
• Chapter Index on page 343 gives you quick access to all relevant data in
this manual.
Conventions used in this manual
To give this manual an easily understood layout and to emphasize important
information, the following typographical styles and symbols are used:
Styles
Symbols
Style Function Example
Bold Programs, inputs or highlighting
important things bold
Courier Code listings etc. Input
Upper case Register REGISTER
Italics Modes, fields Mode
Parentheses and/or blue Links (Link)
Table 2: Styles
Note

This symbol highlights important information.
