Video formats, modes and bandwidth
STINGRAY Technical Manual V4.4.4
220
Format Mode Resolution
Color mode
Maximal S800 frame rates for Format_7 modes
7
0
1032 x 776
1032 x 776
Mono8
Mono12
Mono16
YUV411
YUV422,Raw16
Mono8,Raw8
RGB8
Raw12
31 fps
31 fps
31 fps
31 fps
31 fps
31 fps
27 fps
31 fps
1
516 x 776
Mono8
Mono12
Mono16
31 fps
2x H-binning
31 fps
2x H-binning
31 fps
2x H-binning
2
1032 x 388
Mono8
Mono12
Mono16
53 fps
2x V-binning
53 fps
2x V-binning
53 fps
2x V-binning
3
516 x 388
Mono8
Mono12
Mono16
53 fps
2x H+V binning
53 fps
2x H+V binning
53 fps
2x H+V binning
4
516 x 776
516 x 776
Mono8
Mono12
Mono16
YUV411
YUV422,Raw16
Mono8,Raw8
RGB8
Raw12
31 fps
2 out of 4 H-sub-sampling
31 fps
2 out of 4 H-sub-sampling
31 fps
2 out of 4 H-sub-sampling
31 fps
2 out of 4 H-sub-sampling
31 fps
2 out of 4 H-sub-sampling
31 fps
2 out of 4 H-sub-sampling
31 fps
2 out of 4 H-sub-sampling
31 fps
2 out of 4 H-sub-sampling
5
1032 x 388
1032 x 388
Mono8
Mono12
Mono16
YUV411
YUV422,Raw16
Mono8,Raw8
RGB8
Raw12
39 fps
2 out of 4 V-sub-sampling
39 fps
2 out of 4 V-sub-sampling
39 fps
2 out of 4 V-sub-sampling
39 fps
2 out of 4 V-sub-sampling
39 fps
2 out of 4 V-sub-sampling
39 fps
2 out of 4 V-sub-sampling
39 fps
2 out of 4 V-sub-sampling
39 fps
2 out of 4 V-sub-sampling
6
516 x 388
516 x 388
Mono8
Mono12
Mono16
YUV411
YUV422,Raw16
Mono8,Raw8
RGB8
Raw12
39 fps
2 out of 4 H+V-sub-sampling
39 fps
2 out of 4 H+V-sub-sampling
39 fps
2 out of 4 H+V-sub-sampling
39 fps
2 out of 4 H+V-sub-sampling
39 fps
2 out of 4 H+V-sub-sampling
39 fps
2 out of 4 H+V-sub-sampling
39 fps
2 out of 4 H+V-sub-sampling
39 fps
2 out of 4 H+V sub-sampling
Table 81: Video Format_7 default modes Stingray F-080B /
F-080C
