Camera dimensions
STINGRAY Technical Manual V4.4.4
81
Stingray W270 S90 (2 x 1394b copper)
This version has the sensor tilted by 270 degrees clockwise, so that it views
downwards.
The sensor is also rotated by 90 degrees clockwise.
Figure 32: Stingray W270 S90 (2 x 1394b copper)
Stingray W270S90 (2x IEEE 1394b)
107.3 x 44 x 41.6 (L x W x H)
101
107.3
4
1
.6
2
9
44 47.8 50
16 6 M3 x4 (4x)
M3 x3 (3x)
M3 x3 (3x)
55.5
2
6
1
3
5
.4
1
9
.3
9.7
C-Mount
Q27
9
.1
-
0
.0
0
.3
+
1
3
.4
-
0
.0
0
.3
+
