How does bandwidth affect the frame rate?
STINGRAY Technical Manual V4.4.4
254
ByteDepth is based on the following values:
Example formula for the b/w camera
Mono16, 1392 x 1040, 30 fps desired
Mode
bit/pixel
byte per pixel
Mono8, Raw8
8
1
Mono12, Raw12
12
1.5
Mono16, Raw16
14
2
Mono16, Raw16
(High SNR mode)
16 2
YUV4:2:2
16
2
YUV4:1:1
12
1.5
RGB8
24
3
Table 104: ByteDepth
Formula 19: Example maximum frame rate calculation
BYTE_PER_PACKET
30
1392
1040
2
125µs
10856
8192
=
=
frame rate
reachable
8192
1392
1040
2
125µs
------------------------------------------------------------
22.64
1
s
---
=
